Database manager (DBMAN)

The database structure is divided by concerning with “LC director distribution simulation” and “Optical simulation” and it is categorized into 1) Liquid crystal, 2) Isotropic material, 3) Uniaxial material, 4) Biaxial material, 5) Light source and 6) Dye form the practical requirements. Liquid crystal has both the data of “LC director distribution simulation” and “Optical simulation” and others have only the data of “Optical simulation”. This database dialog is common over 1D, 2D and 3D.

the data for LC director distribution simulation (Liquid crystal)

It inputs elastic constants, relative dielectric constants and viscosity. Installation programs copy typical material data into the specified folders that gets operators to start for working immediately.

the data for optical simulation (LC, isotropic, uniaxial, biaxial and dye)

It inputs wavelength dispersion of refractive index and absorption coefficient from 380nm to 780nm. It also can be extended to deal NIR and NUV region from 200nm to 2000nm. The database files need 10nm step data, but customer no needs to prepare all of data because several interpolation functions are ready for eliminating cumbersome operation.

the functions for interpolation

It prepares Cauchy, Sellmeier, Lorentz, Drude and Spline interpolation functions.

the interpolation functions (with measured data) -> data at another wavelength

When few measured data were supplied, it calculates coefficients of the interpolation function. Operator should choose suitable the function by themselves. Refractive index and absorption coefficients at arbitrary wavelength can be offered by the just chosen interpolation function. It is very convenience for starting simulation immediately.

measured data -> the interpolation function -> data at another wavelength

When many measured data were supplied, it becomes confuse on what the interpolation function is adequate. This new function determines a suitable the interpolation function automatically, like the ellipsometer. It is very easy to get data at arbitrary wavelength when the interpolation function was determined. OPTIPRO is polarimeter supplied by SHINTECH can measure refractive index, too (It depends on the type of machine. Ask our sales department) which outputs those refractive index data.
SHINTECH is a only company provides both the simulator and polarimeter that is most advantage of us!

Light source

It stores light spectra energy into a database. It is also prepared for both 380nm to 780nm and 200nm to 2000nm.
